RFLOXA Hawk36 MaxS Black Front Fork for Arctic Leopard XE PRO S

The RFLOXA Hawk36 MaxS Black Front Fork is designed for the Arctic Leopard XE Pro S and XE Pro S Enduro, giving riders a strong, tunable suspension setup built for electric dirt bike performance. With 228mm of travel, a 37mm tube diameter, and RFLOXA’s inverted oil-spring damping system, this fork is built to handle aggressive trail riding, rough terrain, and heavier electric bike loads.

The Hawk36 MaxS features multi-stage high-speed compression, low-speed compression, rebound, and spring preload adjustments, allowing riders to fine-tune the front-end feel for their weight, terrain, and riding style. The MAX triple clamp is CNC precision machined, while the fork uses AL6061-T6 forged aluminum alloy bottom brackets and AL7075-T6 aluminum fork tubes for strength and durability.

This fork is compatible with 19” and 21” front wheel setups and is designed around Arctic Leopard XE Pro S / XE Pro S Enduro specifications.

Fitment:
Arctic Leopard XE Pro S
Arctic Leopard XE Pro S Enduro

Arctic Leopard XE Pro R Fitment Note:
This fork can be used on the Arctic Leopard XE Pro R, but it is not a direct bolt-on with the stock XE Pro R front brake assembly. To switch an XE Pro R to the RFLOXA front fork setup, the stock front brake assembly must be removed and replaced with Formula EB9 brakes.

The EB9 brake setup is built around the XE Pro S and XE Pro S Enduro post-mount style needed for this fork. Without switching to the EB9 brake setup, the XE Pro R stock front brake assembly will not mount properly to the RFLOXA fork.

Spring Rate Guide:
45 lb spring: Recommended for riders up to 85kg
55 lb spring: Recommended for riders 85kg–120kg

Specs:
Center Distance: 800mm
Main Piston Travel: 228mm
Tube Diameter: 37mm
Caliper Mount Spacing: 90mm
Disc Brake Size: 220mm, upgradeable
Damping System: Inverted oil-spring
Adjustments: High-speed compression, low-speed compression, rebound, spring preload
Material: AL6061-T6 forged aluminum alloy bottom brackets, AL7075-T6 aluminum fork tubes
Spring Wire: 55CRSI
MAX Triple Clamp: CNC precision machined

Install Note:
Upper bearing is not included. To allow fitment across more bike models, the lower bearing is not pre-pressed into the fork, but the fork does include the lower bearing by default.
